| Cell configuration | LF:10" bass unit, HF:1.4" compression driver |
| Frequency response | 50Hz-20kHz±3dB |
| Rated Power | 300W |
| Program Power: | 600W |
| Peak Power: | 1200W |
| The sensitivity | 97dB |
| Maximum loud pressure level | 119dB |
| Standard impedance | 8 Ω |
| Radiation Angle | 90°（H）x 40°（V） |
| Connection mode | 2 x Neutrik NL 4 |
| Hanging way | M8 threaded hole |
| Dimensions(W×D×H): | 298×342×534mm |
| Net weight (kg) | 15KG |
